scikit-learn Machine Learning k-NN algorithm
사이킷런 머신러닝 k-NN 알고리즘

In [1]:

import pandas as pd
import numpy as np
import matplotlib.pyplot as plt
import seaborn as sns

Data Collection¶

In [2]:

# https://archive.ics.uci.edu/ml/datasets/wine
# https://www.kaggle.com/datasets/akhil0007/wine-data

file_url = 'https://raw.githubusercontent.com/dev-EthanJ/scikit-learn_Machine_Learning/main/data/'
data = 'wine.csv'

df = pd.read_csv(file_url + data)

In [3]:

df.head()

Out[3]:

	Class	Alcohol	Malic_Acid	Ash	Ash_Alcanity	Magnesium	Total_Phenols	Flavanoids	Nonflavanoid_Phenols	Proanthocyanins	Color_Intensity	Hue	OD280	Proline
0	1	14.23	1.71	2.43	15.6	127	2.80	3.06	0.28	2.29	5.64	1.04	3.92	1065
1	1	13.20	1.78	2.14	11.2	100	2.65	2.76	0.26	1.28	4.38	1.05	3.40	1050
2	1	13.16	2.36	2.67	18.6	101	2.80	3.24	0.30	2.81	5.68	1.03	3.17	1185
3	1	14.37	1.95	2.50	16.8	113	3.85	3.49	0.24	2.18	7.80	0.86	3.45	1480
4	1	13.24	2.59	2.87	21.0	118	2.80	2.69	0.39	1.82	4.32	1.04	2.93	735

In [4]:

df.info()

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 178 entries, 0 to 177
Data columns (total 14 columns):
 #   Column                Non-Null Count  Dtype
---  ------                --------------  -----
 0   Class                 178 non-null    int64
 1   Alcohol               178 non-null    float64
 2   Malic_Acid            178 non-null    float64
 3   Ash                   178 non-null    float64
 4   Ash_Alcanity          178 non-null    float64
 5   Magnesium             178 non-null    int64
 6   Total_Phenols         178 non-null    float64
 7   Flavanoids            178 non-null    float64
 8   Nonflavanoid_Phenols  178 non-null    float64
 9   Proanthocyanins       178 non-null    float64
 10  Color_Intensity       178 non-null    float64
 11  Hue                   178 non-null    float64
 12  OD280                 178 non-null    float64
 13  Proline               178 non-null    int64
dtypes: float64(11), int64(3)
memory usage: 19.6 KB

• 결측치 없음
• 모두 수치화 된 data

In [5]:

pd.options.display.float_format = '{:,.4f}'.format
# 기술 통계
df.describe()

Out[5]:

	Class	Alcohol	Malic_Acid	Ash	Ash_Alcanity	Magnesium	Total_Phenols	Flavanoids	Nonflavanoid_Phenols	Proanthocyanins	Color_Intensity	Hue	OD280	Proline
count	178.0000	178.0000	178.0000	178.0000	178.0000	178.0000	178.0000	178.0000	178.0000	178.0000	178.0000	178.0000	178.0000	178.0000
mean	1.9382	13.0006	2.3363	2.3665	19.4949	99.7416	2.2951	2.0293	0.3619	1.5909	5.0581	0.9574	2.6117	746.8933
std	0.7750	0.8118	1.1171	0.2743	3.3396	14.2825	0.6259	0.9989	0.1245	0.5724	2.3183	0.2286	0.7100	314.9075
min	1.0000	11.0300	0.7400	1.3600	10.6000	70.0000	0.9800	0.3400	0.1300	0.4100	1.2800	0.4800	1.2700	278.0000
25%	1.0000	12.3625	1.6025	2.2100	17.2000	88.0000	1.7425	1.2050	0.2700	1.2500	3.2200	0.7825	1.9375	500.5000
50%	2.0000	13.0500	1.8650	2.3600	19.5000	98.0000	2.3550	2.1350	0.3400	1.5550	4.6900	0.9650	2.7800	673.5000
75%	3.0000	13.6775	3.0825	2.5575	21.5000	107.0000	2.8000	2.8750	0.4375	1.9500	6.2000	1.1200	3.1700	985.0000
max	3.0000	14.8300	5.8000	3.2300	30.0000	162.0000	3.8800	5.0800	0.6600	3.5800	13.0000	1.7100	4.0000	1,680.0000

1. 변수마다 값의 범위가 다름

   • Nonflavanoid_Phenols : 0.13 ~ 0.66

   • Proline : 278 ~ 1680

• 🤔 스케일링(scaling) : 독립변수의 범위를 동일한 수준으로 만들어주는 기법

1. Outlier(이상치)

   • color_inensity : 75% ~ max : 6.2 ~ 13: 2배 이상 증가

목표 value에서 고유값 check¶

In [6]:

df['Class'].unique()

Out[6]:

array([1, 2, 3])

In [7]:

df.Class.value_counts()

Out[7]:

2    71
1    59
3    48
Name: Class, dtype: int64

고유값 Bar Chart Visualization¶

In [8]:

value_counts = df.Class.value_counts()

# column 'Class' 분포 시각화 확인
sns.barplot(x=value_counts.index, y=value_counts)
plt.show()

Data pre-processing¶

스케일링(Scaling)¶

• 데이터의 스케일(Scale, 범위)을 맞추는 작업

• K-최근접 이웃은 거리 기반의 알고리즘이기 때문에 이러한 스케일 차이는 결과를 왜곡할 수 있음

• 스케일링은 이러한 문제를 해결하기 위해 인위적으로 각 컬럼(변수)이 비슷한 범위를 가지도록 만드는 작업

• 데이터를 동등한 수준에서 연산하게 함

스케일링 종류¶

종류	설명
표준화 스케일링 Standarad Scaling	평균이 0이 되고, 표준편차가 1이 되도록 데이터를 고르게 분포시키는 데 사용
로버스트 스케일링 Robust Scaling	데이터에 아웃라이어가 존재하고, 그 영향력을 그대로 유지하고 싶을 때 사용
최소-최대 스케일링 Min-Max Scaling	데이터 분포의 특성을 최대한 그대로 유지하고 싶을 때 사용
정규화 스케일링Normalizer Scaling	행 기준의 스케일링이 필요할 때 사용하나, 실제로 거의 사용하지 않음

• 평균을 사용하면 Outlier(이상치)에게 당한다!

In [9]:

from sklearn.preprocessing import StandardScaler, MinMaxScaler, RobustScaler

표준화 스케일링¶

데이터를 표준정규분포 형태로 변형

$x_i-mean(x)\over sd(x)$

• $x_i$ : 변수의 i번째 값
• $mean(x)$ : 해당 변수의 평균
• $sd(x)$ : 해당 변수의 표준편차

In [10]:

std_scaler = StandardScaler()

std_scaler.fit(df)

Out[10]:

StandardScaler()

• StandardScaler.transform(DataFrame): Scaler가 fit()을 통해 학습한 정보를 기반으로 data를 scaling하게 하는 함수

In [11]:

std_scaled = std_scaler.transform(df)

std_scaled

Out[11]:

array([[-1.21394365,  1.51861254, -0.5622498 , ...,  0.36217728,
         1.84791957,  1.01300893],
       [-1.21394365,  0.24628963, -0.49941338, ...,  0.40605066,
         1.1134493 ,  0.96524152],
       [-1.21394365,  0.19687903,  0.02123125, ...,  0.31830389,
         0.78858745,  1.39514818],
       ...,
       [ 1.37386437,  0.33275817,  1.74474449, ..., -1.61212515,
        -1.48544548,  0.28057537],
       [ 1.37386437,  0.20923168,  0.22769377, ..., -1.56825176,
        -1.40069891,  0.29649784],
       [ 1.37386437,  1.39508604,  1.58316512, ..., -1.52437837,
        -1.42894777, -0.59516041]])

In [12]:

df_std_scaled = pd.DataFrame(std_scaled, columns=df.columns)

df_std_scaled.head(10)

Out[12]:

	Class	Alcohol	Malic_Acid	Ash	Ash_Alcanity	Magnesium	Total_Phenols	Flavanoids	Nonflavanoid_Phenols	Proanthocyanins	Color_Intensity	Hue	OD280	Proline
0	-1.2139	1.5186	-0.5622	0.2321	-1.1696	1.9139	0.8090	1.0348	-0.6596	1.2249	0.2517	0.3622	1.8479	1.0130
1	-1.2139	0.2463	-0.4994	-0.8280	-2.4908	0.0181	0.5686	0.7336	-0.8207	-0.5447	-0.2933	0.4061	1.1134	0.9652
2	-1.2139	0.1969	0.0212	1.1093	-0.2687	0.0884	0.8090	1.2155	-0.4984	2.1360	0.2690	0.3183	0.7886	1.3951
3	-1.2139	1.6915	-0.3468	0.4879	-0.8093	0.9309	2.4914	1.4665	-0.9819	1.0322	1.1861	-0.4275	1.1841	2.3346
4	-1.2139	0.2957	0.2277	1.8404	0.4519	1.2820	0.8090	0.6634	0.2268	0.4014	-0.3193	0.3622	0.4496	-0.0379
5	-1.2139	1.4816	-0.5174	0.3052	-1.2897	0.8607	1.5621	1.3661	-0.1761	0.6642	0.7319	0.4061	0.3366	2.2390
6	-1.2139	1.7163	-0.4186	0.3052	-1.4699	-0.2627	0.3283	0.4927	-0.4984	0.6817	0.0830	0.2744	1.3677	1.7295
7	-1.2139	1.3086	-0.1673	0.8900	-0.5690	1.4926	0.4885	0.4826	-0.4178	-0.5973	-0.0035	0.4499	1.3677	1.7454
8	-1.2139	2.2598	-0.6251	-0.7183	-1.6500	-0.1925	0.8090	0.9545	-0.5790	0.6817	0.0614	0.5377	0.3366	0.9493
9	-1.2139	1.0616	-0.8854	-0.3528	-1.0495	-0.1223	1.0974	1.1252	-1.1430	0.4540	0.9352	0.2306	1.3253	0.9493

In [13]:

pd.options.display.float_format = '{:,.2f}'.format

# 표준화: mean = 0, std = 1
df_std_scaled.describe()

Out[13]:

	Class	Alcohol	Malic_Acid	Ash	Ash_Alcanity	Magnesium	Total_Phenols	Flavanoids	Nonflavanoid_Phenols	Proanthocyanins	Color_Intensity	Hue	OD280	Proline
count	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00
mean	0.00	-0.00	-0.00	-0.00	-0.00	-0.00	0.00	-0.00	0.00	-0.00	0.00	0.00	0.00	-0.00
std	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00
min	-1.21	-2.43	-1.43	-3.68	-2.67	-2.09	-2.11	-1.70	-1.87	-2.07	-1.63	-2.09	-1.90	-1.49
25%	-1.21	-0.79	-0.66	-0.57	-0.69	-0.82	-0.89	-0.83	-0.74	-0.60	-0.80	-0.77	-0.95	-0.78
50%	0.08	0.06	-0.42	-0.02	0.00	-0.12	0.10	0.11	-0.18	-0.06	-0.16	0.03	0.24	-0.23
75%	1.37	0.84	0.67	0.70	0.60	0.51	0.81	0.85	0.61	0.63	0.49	0.71	0.79	0.76
max	1.37	2.26	3.11	3.16	3.15	4.37	2.54	3.06	2.40	3.49	3.44	3.30	1.96	2.97

로버스트 스케일링¶

사분위값을 이용하여 계산

$x_i-Q_2(x)\over Q_3(x)-Q_1(x)$

• $x_i$ : 변수의 i번째 값
• $Q_1(x)$ : 25% 지점
• $Q_2(x)$ : 50% 지점 (변수의 중윗값)
• $Q_3(x)$ : 75% 지점

In [14]:

rb_scaler = RobustScaler()

• fit() + transform() = Scaler.fit_transform(DataFrame)

In [15]:

rb_scaled = rb_scaler.fit_transform(df)
df_rb_scaled = pd.DataFrame(rb_scaled, columns=df.columns)

df_rb_scaled.describe()

Out[15]:

	Class	Alcohol	Malic_Acid	Ash	Ash_Alcanity	Magnesium	Total_Phenols	Flavanoids	Nonflavanoid_Phenols	Proanthocyanins	Color_Intensity	Hue	OD280	Proline
count	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00
mean	-0.03	-0.04	0.32	0.02	-0.00	0.09	-0.06	-0.06	0.13	0.05	0.12	-0.02	-0.14	0.15
std	0.39	0.62	0.75	0.79	0.78	0.75	0.59	0.60	0.74	0.82	0.78	0.68	0.58	0.65
min	-0.50	-1.54	-0.76	-2.88	-2.07	-1.47	-1.30	-1.07	-1.25	-1.64	-1.14	-1.44	-1.23	-0.82
25%	-0.50	-0.52	-0.18	-0.43	-0.53	-0.53	-0.58	-0.56	-0.42	-0.44	-0.49	-0.54	-0.68	-0.36
50%	0.00	0.00	-0.00	0.00	0.00	0.00	0.00	0.00	0.00	-0.00	0.00	0.00	0.00	0.00
75%	0.50	0.48	0.82	0.57	0.47	0.47	0.42	0.44	0.58	0.56	0.51	0.46	0.32	0.64
max	0.50	1.35	2.66	2.50	2.44	3.37	1.44	1.76	1.91	2.89	2.79	2.21	0.99	2.08

최소-최대 스케일링¶

최솟값, 최댓값을 사용하여 스케일링, 모든 컬럼에서 최댓값이 1, 최솟값이 0인 형태로 변환됨

$x_i-min(x)\over max(x)-min(x)$

• $x_i$ : 변수의 i번째 값
• $min(x)$ : 최솟값
• $max(x)$ : 최댓값

In [16]:

mm_scaler = MinMaxScaler()

mm_scaled = mm_scaler.fit_transform(df)
df_mm_scaled = pd.DataFrame(mm_scaled, columns=df.columns)

df_mm_scaled.describe()

Out[16]:

	Class	Alcohol	Malic_Acid	Ash	Ash_Alcanity	Magnesium	Total_Phenols	Flavanoids	Nonflavanoid_Phenols	Proanthocyanins	Color_Intensity	Hue	OD280	Proline
count	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00	178.00
mean	0.47	0.52	0.32	0.54	0.46	0.32	0.45	0.36	0.44	0.37	0.32	0.39	0.49	0.33
std	0.39	0.21	0.22	0.15	0.17	0.16	0.22	0.21	0.23	0.18	0.20	0.19	0.26	0.22
min	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00
25%	0.00	0.35	0.17	0.45	0.34	0.20	0.26	0.18	0.26	0.26	0.17	0.25	0.24	0.16
50%	0.50	0.53	0.22	0.53	0.46	0.30	0.47	0.38	0.40	0.36	0.29	0.39	0.55	0.28
75%	1.00	0.70	0.46	0.64	0.56	0.40	0.63	0.53	0.58	0.49	0.42	0.52	0.70	0.50
max	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00

스케일링 방식 선택 기준¶

• 아웃라이어의 유무 : 아웃라이어 영향이 클 시: 로버스트 스케일링 (4분위값 이용)
• 데이터의 기존 분포를 최대한 유지해야할 시 : 최소-최대 스케일링
• 기존 데이터가 정규분포를 따르고 있고 아웃라이어가 없는 상황 : 표준화 스케일링

스케일링별 특징¶

구분	결과물의 특징
표준화 스케일링	아웃라이어의 영향을 받음. 평균 0, 분산 1이 되게끔 분포시키기 때문에, 데이터의 기존 분포 형태가 사라지고 정규분포를 따르는 결과물을 가져 옴
로버스트 스케일링	데이터에 아웃라이어가 존재할 때, 아웃라이어의 영향을 받지 않음. 변환된 데이터의 범위는 표준화 스케일링이나 최소-최대 스케일링보다 넓게 나타남
최소-최대 스케일링	아웃라이어의 영향을 받음. 위의 두 스케일러와 비교했을 때, 데이터의 기존 분포를 가장 있는 그대로 담아내며 스케일만 변화시킴. 데이터의 범위는 0~1로 나타남

스케일링 적용 시 주의점¶

• 스케일링 대상에서 종속변수를 제외: 종속변수가 model 예측 대상이다
• 스케일링 전 train set과 test set을 구분: modeling에 영향을 끼치는 것들은 미리 선정

Scaling¶

: Outlier의 영향 줄이기, 범위에 따른 거리의 왜곡 줄이기

• 훈련의 대상이 되는 데이터 vs. 시험의 대상이 되는 데이터: 독립돼 있어야 함

• 만약 둘을 합쳐서 scaling을 하면, scale의 기준 data(minmax, mean, 4분위 값)이 공유됨

  • train set을 대상으로만 scaling: scaler 학습 (train set 학습 scaler)

  • test set도 이미 학습된 scaler(train set 학습된 scaler)로 scaling을 진행

• train set과 test set 분리

In [17]:

from sklearn.model_selection import train_test_split

X_train, X_test, y_train, y_test = train_test_split(
    df.drop(columns=['Class']),
    df['Class'],
    test_size = 0.3, random_state = 814
)

• 데이터 특성 보존을 위해 MinMaxScaler 사용

In [18]:

mm_scaler = MinMaxScaler()

• 클래스를 통해 만들어진 변수와 함수의 묶음: 객체 (object, instance)

  • 객체에 소속된 변수: property

  • 객체에 소속된 함수: method

In [19]:

X_train_scaled = mm_scaler.fit_transform(X_train)

# mm_scaler가 이미 fitting되었기 때문에 transform(scaling)만 진행
X_test_scaled = mm_scaler.transform(X_test)

Training Model¶

In [20]:

from sklearn.neighbors import KNeighborsClassifier

In [21]:

knn = KNeighborsClassifier()
knn.fit(X_train_scaled, y_train)
pred = knn.predict(X_test_scaled)

pred

Out[21]:

array([3, 3, 1, 2, 2, 3, 2, 1, 2, 2, 3, 1, 1, 3, 2, 2, 3, 1, 2, 1, 2, 3,
       3, 2, 2, 2, 2, 1, 2, 1, 2, 3, 1, 3, 1, 2, 1, 3, 2, 2, 2, 2, 3, 3,
       1, 2, 1, 1, 2, 1, 1, 2, 2, 3])

Evaluating Model¶

In [22]:

from sklearn.metrics import accuracy_score

accuracy_score(y_test, pred)

Out[22]:

0.9814814814814815

Scaling되지 않은 Data 사용 > accuracy_score 하락¶

In [23]:

new_knn = KNeighborsClassifier()
new_knn.fit(X_train, y_train)
new_pred = new_knn.predict(X_test)

accuracy_score(y_test, new_pred)

Out[23]:

0.7592592592592593

하이퍼파라미터 튜닝(Hyperparameter tuning or optimization)¶

• parameter를 통해서 algorithms에 들어가는 values setting

  • 항상 같은 parameter value가 적용되는 게 맞을까?

• KNeighborsClassifier: 분류 문제 알고리즘

  • n_neighbors=5: 예측에 참고할 이웃 수

  • weights='uniform': 예측에 사용되는 가중치 함수, default인 uniform은 모든 포인트에 동일한 가중치가 부여.
    > 'uniform', 'distance', 사용자 정의 함수 가능

  • metric='minkowski': 거리 측정 기준 (DistanceMetric)

  • n_jobs=None: 실행할 병렬 작업 수

별도로 지정해주지 않으면 기본값으로 반영
알고리즘에 쓰이는 매개변수를 조정 = Hyperparameter tuning

In [24]:

# hyperparameter tuning 함수화
def tuning(n: int) -> float:
  knn = KNeighborsClassifier(n_neighbors=n)

  # fit할 때 setting됨
  knn.fit(X_train_scaled, y_train)

  pred = knn.predict(X_test_scaled)
  score = accuracy_score(y_test, pred)
  return score

In [25]:

# n_neighbors=1
tuning(1)

Out[25]:

0.9444444444444444

In [26]:

scores = [(i+1, tuning(i+1)) for i in range(20)]

scores

Out[26]:

[(1, 0.9444444444444444),
 (2, 0.9444444444444444),
 (3, 0.9444444444444444),
 (4, 0.9814814814814815),
 (5, 0.9814814814814815),
 (6, 0.9629629629629629),
 (7, 0.9814814814814815),
 (8, 0.9814814814814815),
 (9, 0.9814814814814815),
 (10, 0.9814814814814815),
 (11, 0.9814814814814815),
 (12, 0.9814814814814815),
 (13, 0.9814814814814815),
 (14, 0.9814814814814815),
 (15, 0.9814814814814815),
 (16, 0.9814814814814815),
 (17, 0.9814814814814815),
 (18, 0.9629629629629629),
 (19, 0.9814814814814815),
 (20, 0.9814814814814815)]

In [27]:

sorted(scores, key=lambda x: x[1], reverse=True)

Out[27]:

[(4, 0.9814814814814815),
 (5, 0.9814814814814815),
 (7, 0.9814814814814815),
 (8, 0.9814814814814815),
 (9, 0.9814814814814815),
 (10, 0.9814814814814815),
 (11, 0.9814814814814815),
 (12, 0.9814814814814815),
 (13, 0.9814814814814815),
 (14, 0.9814814814814815),
 (15, 0.9814814814814815),
 (16, 0.9814814814814815),
 (17, 0.9814814814814815),
 (19, 0.9814814814814815),
 (20, 0.9814814814814815),
 (6, 0.9629629629629629),
 (18, 0.9629629629629629),
 (1, 0.9444444444444444),
 (2, 0.9444444444444444),
 (3, 0.9444444444444444)]

KNN 알고리즘 이해¶

• KNN 알고리즘 : 새로운 데이터를 예측할 때, 거리를 기반으로 하여 인접한 데이터과 같은 종류로 분류

• 변수의 스케일 간의 격차가 클 경우, 산출되는 거리값이 왜곡될 수 있음

• 거리가 동점일 경우

  • scikit-learn: 랜덤으로 분류함

  • n을 홀수로 하면 동점을 근본적으로 막을 수 있음

  • 그럼에도 짝수를 써야한다면 weights를 통해 가중치를 줌

연습

• 타이타닉 데이터에 KNN을 통해 분류 진행

• 스케일러(표준화, 로버스트, 최소-최대)별 결과 비교

Titanic Data Prediction by k-NN Algorithm¶

1. Data Collection

2. Data pre-processing

3. Training Model

4. Evaluating Model

Data Collection¶

In [28]:

file_url = 'https://raw.githubusercontent.com/dev-EthanJ/scikit-learn_Machine_Learning/main/data/titanic_train.csv'
df_train = pd.read_csv(file_url, index_col=0)

df_train.head()

Out[28]:

	Survived	Pclass	Name	Sex	Age	SibSp	Parch	Ticket	Fare	Cabin	Embarked
PassengerId
1	0	3	Braund, Mr. Owen Harris	male	22.00	1	0	A/5 21171	7.25	NaN	S
2	1	1	Cumings, Mrs. John Bradley (Florence Briggs Th...	female	38.00	1	0	PC 17599	71.28	C85	C
3	1	3	Heikkinen, Miss. Laina	female	26.00	0	0	STON/O2. 3101282	7.92	NaN	S
4	1	1	Futrelle, Mrs. Jacques Heath (Lily May Peel)	female	35.00	1	0	113803	53.10	C123	S
5	0	3	Allen, Mr. William Henry	male	35.00	0	0	373450	8.05	NaN	S

In [29]:

df_train.info()

<class 'pandas.core.frame.DataFrame'>
Int64Index: 891 entries, 1 to 891
Data columns (total 11 columns):
 #   Column    Non-Null Count  Dtype
---  ------    --------------  -----
 0   Survived  891 non-null    int64
 1   Pclass    891 non-null    int64
 2   Name      891 non-null    object
 3   Sex       891 non-null    object
 4   Age       714 non-null    float64
 5   SibSp     891 non-null    int64
 6   Parch     891 non-null    int64
 7   Ticket    891 non-null    object
 8   Fare      891 non-null    float64
 9   Cabin     204 non-null    object
 10  Embarked  889 non-null    object
dtypes: float64(2), int64(4), object(5)
memory usage: 83.5+ KB

In [30]:

df_train.columns

Out[30]:

Index(['Survived', 'Pclass', 'Name', 'Sex', 'Age', 'SibSp', 'Parch', 'Ticket',
       'Fare', 'Cabin', 'Embarked'],
      dtype='object')

Data pre-processing¶

결측치 처리: Cabin¶

In [31]:

df_train.Cabin.nunique()

Out[31]:

147

• 너무 다양하고 결측치 많음 → drop

In [32]:

df_train = df_train.drop(['Cabin'], axis=1)

결측치 처리: Embarked¶

In [33]:

sample = df_train.copy()

In [34]:

sample.Embarked.value_counts()

Out[34]:

S    644
C    168
Q     77
Name: Embarked, dtype: int64

In [35]:

sample.Embarked.unique()

Out[35]:

array(['S', 'C', 'Q', nan], dtype=object)

• 최빈값 'S'로 .fillna()

In [36]:

sample.Embarked = sample.Embarked.fillna('S')

sample.Embarked.isnull().sum()

Out[36]:

0

In [37]:

sample.head()

Out[37]:

	Survived	Pclass	Name	Sex	Age	SibSp	Parch	Ticket	Fare	Embarked
PassengerId
1	0	3	Braund, Mr. Owen Harris	male	22.00	1	0	A/5 21171	7.25	S
2	1	1	Cumings, Mrs. John Bradley (Florence Briggs Th...	female	38.00	1	0	PC 17599	71.28	C
3	1	3	Heikkinen, Miss. Laina	female	26.00	0	0	STON/O2. 3101282	7.92	S
4	1	1	Futrelle, Mrs. Jacques Heath (Lily May Peel)	female	35.00	1	0	113803	53.10	S
5	0	3	Allen, Mr. William Henry	male	35.00	0	0	373450	8.05	S

In [38]:

df_train = sample

무수한 value column 처리: Ticket¶

In [39]:

df_train['Ticket'].nunique()

Out[39]:

681

In [40]:

df_train = df_train.drop(columns=['Ticket'])

df_train.columns

Out[40]:

Index(['Survived', 'Pclass', 'Name', 'Sex', 'Age', 'SibSp', 'Parch', 'Fare',
       'Embarked'],
      dtype='object')

Name column: Title column 추출¶

In [41]:

df_train['Title'] = df_train.Name.str.extract('([A-Za-z]+)\.')

df_train.Title.value_counts()

Out[41]:

Mr          517
Miss        182
Mrs         125
Master       40
Dr            7
Rev           6
Mlle          2
Major         2
Col           2
Countess      1
Capt          1
Ms            1
Sir           1
Lady          1
Mme           1
Don           1
Jonkheer      1
Name: Title, dtype: int64

• 10개 미만의 개수를 가진 value를 rare_list에 추가

In [42]:

title_unique = df_train.Title.unique()

rare_list = [title for title in title_unique if df_train.Title.value_counts()[title] < 10]

rare_list

Out[42]:

['Don',
 'Rev',
 'Dr',
 'Mme',
 'Ms',
 'Major',
 'Lady',
 'Sir',
 'Mlle',
 'Col',
 'Capt',
 'Countess',
 'Jonkheer']

In [43]:

df_train.Title = df_train.Title.replace(rare_list, 'Rare')

df_train.Title.value_counts()

Out[43]:

Mr        517
Miss      182
Mrs       125
Master     40
Rare       27
Name: Title, dtype: int64

• 각 Title별 Age의 평균

In [44]:

title_age_mean = df_train.groupby('Title')['Age'].mean()

title_age_mean

Out[44]:

Title
Master    4.57
Miss     21.77
Mr       32.37
Mrs      35.90
Rare     42.38
Name: Age, dtype: float64

In [45]:

for title in df_train.Title.unique():
    df_train.loc[(df_train.Age.isnull()) & (df_train.Title == title), 'Age'] = title_age_mean[title]

df_train.info()

<class 'pandas.core.frame.DataFrame'>
Int64Index: 891 entries, 1 to 891
Data columns (total 10 columns):
 #   Column    Non-Null Count  Dtype
---  ------    --------------  -----
 0   Survived  891 non-null    int64
 1   Pclass    891 non-null    int64
 2   Name      891 non-null    object
 3   Sex       891 non-null    object
 4   Age       891 non-null    float64
 5   SibSp     891 non-null    int64
 6   Parch     891 non-null    int64
 7   Fare      891 non-null    float64
 8   Embarked  891 non-null    object
 9   Title     891 non-null    object
dtypes: float64(2), int64(4), object(4)
memory usage: 76.6+ KB

In [46]:

df_train = df_train.drop(columns=['Name'])

df_train.columns

Out[46]:

Index(['Survived', 'Pclass', 'Sex', 'Age', 'SibSp', 'Parch', 'Fare',
       'Embarked', 'Title'],
      dtype='object')

In [47]:

for col in df_train.columns:
  print(col, df_train[col].nunique(), df_train[col].dtype)

Survived 2 int64
Pclass 3 int64
Sex 2 object
Age 93 float64
SibSp 7 int64
Parch 7 int64
Fare 248 float64
Embarked 3 object
Title 5 object

In [48]:

df_train.info()

<class 'pandas.core.frame.DataFrame'>
Int64Index: 891 entries, 1 to 891
Data columns (total 9 columns):
 #   Column    Non-Null Count  Dtype
---  ------    --------------  -----
 0   Survived  891 non-null    int64
 1   Pclass    891 non-null    int64
 2   Sex       891 non-null    object
 3   Age       891 non-null    float64
 4   SibSp     891 non-null    int64
 5   Parch     891 non-null    int64
 6   Fare      891 non-null    float64
 7   Embarked  891 non-null    object
 8   Title     891 non-null    object
dtypes: float64(2), int64(4), object(3)
memory usage: 69.6+ KB

Categorical data (Dtype=object): .get_dummies()¶

In [49]:

df_train.info()

<class 'pandas.core.frame.DataFrame'>
Int64Index: 891 entries, 1 to 891
Data columns (total 9 columns):
 #   Column    Non-Null Count  Dtype
---  ------    --------------  -----
 0   Survived  891 non-null    int64
 1   Pclass    891 non-null    int64
 2   Sex       891 non-null    object
 3   Age       891 non-null    float64
 4   SibSp     891 non-null    int64
 5   Parch     891 non-null    int64
 6   Fare      891 non-null    float64
 7   Embarked  891 non-null    object
 8   Title     891 non-null    object
dtypes: float64(2), int64(4), object(3)
memory usage: 69.6+ KB

In [50]:

df_train = pd.get_dummies(df_train, columns=['Sex', 'Embarked', 'Title'])

df_train.info()

<class 'pandas.core.frame.DataFrame'>
Int64Index: 891 entries, 1 to 891
Data columns (total 16 columns):
 #   Column        Non-Null Count  Dtype
---  ------        --------------  -----
 0   Survived      891 non-null    int64
 1   Pclass        891 non-null    int64
 2   Age           891 non-null    float64
 3   SibSp         891 non-null    int64
 4   Parch         891 non-null    int64
 5   Fare          891 non-null    float64
 6   Sex_female    891 non-null    uint8
 7   Sex_male      891 non-null    uint8
 8   Embarked_C    891 non-null    uint8
 9   Embarked_Q    891 non-null    uint8
 10  Embarked_S    891 non-null    uint8
 11  Title_Master  891 non-null    uint8
 12  Title_Miss    891 non-null    uint8
 13  Title_Mr      891 non-null    uint8
 14  Title_Mrs     891 non-null    uint8
 15  Title_Rare    891 non-null    uint8
dtypes: float64(2), int64(4), uint8(10)
memory usage: 57.4 KB

In [51]:

pd.options.display.float_format = '{:,.4f}'.format

df_train.describe()

Out[51]:

	Survived	Pclass	Age	SibSp	Parch	Fare	Sex_female	Sex_male	Embarked_C	Embarked_Q	Embarked_S	Title_Master	Title_Miss	Title_Mr	Title_Mrs	Title_Rare
count	891.0000	891.0000	891.0000	891.0000	891.0000	891.0000	891.0000	891.0000	891.0000	891.0000	891.0000	891.0000	891.0000	891.0000	891.0000	891.0000
mean	0.3838	2.3086	29.7551	0.5230	0.3816	32.2042	0.3524	0.6476	0.1886	0.0864	0.7250	0.0449	0.2043	0.5802	0.1403	0.0303
std	0.4866	0.8361	13.2776	1.1027	0.8061	49.6934	0.4780	0.4780	0.3914	0.2811	0.4468	0.2072	0.4034	0.4938	0.3475	0.1715
min	0.0000	1.0000	0.4200	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000
25%	0.0000	2.0000	21.7740	0.0000	0.0000	7.9104	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000
50%	0.0000	3.0000	30.0000	0.0000	0.0000	14.4542	0.0000	1.0000	0.0000	0.0000	1.0000	0.0000	0.0000	1.0000	0.0000	0.0000
75%	1.0000	3.0000	35.8981	1.0000	0.0000	31.0000	1.0000	1.0000	0.0000	0.0000	1.0000	0.0000	0.0000	1.0000	0.0000	0.0000
max	1.0000	3.0000	80.0000	8.0000	6.0000	512.3292	1.0000	1.0000	1.0000	1.0000	1.0000	1.0000	1.0000	1.0000	1.0000	1.0000

Training Model: MinMaxScaler¶

In [52]:

# train set과 test set 분리
from sklearn.model_selection import train_test_split

X_train, X_test, y_train, y_test = train_test_split(
    # 'Survived' column: 종속 변수
    df_train.drop('Survived', axis=1),
    df_train.Survived, test_size = 0.2, random_state = 814
)

In [53]:

from sklearn.preprocessing import MinMaxScaler

mm_scaler = MinMaxScaler()

X_train_scaled = mm_scaler.fit_transform(X_train)
X_test_scaled = mm_scaler.transform(X_test)

In [54]:

from sklearn.neighbors import KNeighborsClassifier

knn = KNeighborsClassifier()
knn.fit(X_train_scaled, y_train)
pred = knn.predict(X_test_scaled)

pred

Out[54]:

array([1, 0, 0, 0, 0, 0, 1, 1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 1,
       0, 0, 1, 0, 0, 1, 0, 1, 1, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0,
       0, 1, 0, 0, 0, 0, 1, 0, 0, 1, 0, 0, 0, 0, 0, 0, 1, 1, 1, 0, 1, 0,
       0, 0, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 1,
       0, 1, 0, 0, 0, 1, 0, 0, 0, 0, 0, 0, 1, 1, 0, 0, 0, 0, 1, 0, 0, 0,
       1, 0, 1, 0, 0, 0, 0, 0, 1, 0, 0, 1, 0, 0, 0, 1, 0, 1, 0, 0, 1, 0,
       0, 0, 0, 1, 0, 0, 0, 0, 0, 0, 0, 1, 0, 0, 1, 1, 0, 0, 0, 1, 0, 0,
       0, 0, 1, 1, 0, 0, 0, 0, 0, 1, 0, 0, 0, 1, 0, 0, 0, 1, 1, 0, 1, 0,
       1, 0, 0])

Evaluating Model¶

In [55]:

from sklearn.metrics import accuracy_score

accuracy_score(y_test, pred)

Out[55]:

0.8156424581005587

In [56]:

def tuning(n: int) -> float:
  knn = KNeighborsClassifier(n_neighbors=n)
  # fit할 때 hyperparameter tuning됨
  knn.fit(X_train_scaled, y_train)

  pred = knn.predict(X_test_scaled)
  score = accuracy_score(y_test, pred)
  return score

In [57]:

train_list = [[i, tuning(i)] for i in range(1,51)]

In [58]:

sorted_list = sorted(train_list, key=lambda x: x[1], reverse=True)

sorted_list

Out[58]:

[[15, 0.8324022346368715],
 [14, 0.8268156424581006],
 [13, 0.8212290502793296],
 [16, 0.8212290502793296],
 [5, 0.8156424581005587],
 [17, 0.8156424581005587],
 [26, 0.8156424581005587],
 [27, 0.8156424581005587],
 [8, 0.8100558659217877],
 [3, 0.8044692737430168],
 [4, 0.8044692737430168],
 [11, 0.8044692737430168],
 [12, 0.8044692737430168],
 [28, 0.8044692737430168],
 [29, 0.8044692737430168],
 [30, 0.8044692737430168],
 [31, 0.8044692737430168],
 [32, 0.8044692737430168],
 [33, 0.8044692737430168],
 [35, 0.8044692737430168],
 [7, 0.7988826815642458],
 [34, 0.7988826815642458],
 [37, 0.7988826815642458],
 [10, 0.7932960893854749],
 [18, 0.7932960893854749],
 [23, 0.7932960893854749],
 [24, 0.7932960893854749],
 [25, 0.7932960893854749],
 [6, 0.7877094972067039],
 [19, 0.7877094972067039],
 [21, 0.7877094972067039],
 [36, 0.7877094972067039],
 [38, 0.7877094972067039],
 [39, 0.7877094972067039],
 [40, 0.7877094972067039],
 [41, 0.7877094972067039],
 [42, 0.7877094972067039],
 [43, 0.7877094972067039],
 [44, 0.7877094972067039],
 [45, 0.7877094972067039],
 [46, 0.7877094972067039],
 [50, 0.7877094972067039],
 [2, 0.7821229050279329],
 [9, 0.7821229050279329],
 [20, 0.7821229050279329],
 [22, 0.7821229050279329],
 [47, 0.7821229050279329],
 [48, 0.7821229050279329],
 [49, 0.7821229050279329],
 [1, 0.7150837988826816]]

In [59]:

f'타이타닉 데이터셋으로, k-NN 알고리즘 기반 MinMaxScailing 사용시 k={sorted_list[0][0]}에서 {sorted_list[0][1] * 100}%의 예측 정확도를 보였다.'

Out[59]:

'타이타닉 데이터셋으로, k-NN 알고리즘 기반 MinMaxScailing 사용시 k=15에서 83.24022346368714%의 예측 정확도를 보였다.'

In [60]:

df_corr = df_train.corr()

df_corr

Out[60]:

	Survived	Pclass	Age	SibSp	Parch	Fare	Sex_female	Sex_male	Embarked_C	Embarked_Q	Embarked_S	Title_Master	Title_Miss	Title_Mr	Title_Mrs	Title_Rare
Survived	1.0000	-0.3385	-0.0892	-0.0353	0.0816	0.2573	0.5434	-0.5434	0.1682	0.0037	-0.1497	0.0852	0.3271	-0.5492	0.3390	0.0220
Pclass	-0.3385	1.0000	-0.3436	0.0831	0.0184	-0.5495	-0.1319	0.1319	-0.2433	0.2210	0.0741	0.0821	-0.0006	0.1427	-0.1492	-0.2063
Age	-0.0892	-0.3436	1.0000	-0.2677	-0.1968	0.0911	-0.1174	0.1174	0.0414	-0.0478	-0.0062	-0.4114	-0.3047	0.2315	0.1870	0.1682
SibSp	-0.0353	0.0831	-0.2677	1.0000	0.4148	0.1597	0.1146	-0.1146	-0.0595	-0.0264	0.0687	0.3496	0.0879	-0.2505	0.0634	-0.0364
Parch	0.0816	0.0184	-0.1968	0.4148	1.0000	0.2162	0.2455	-0.2455	-0.0111	-0.0812	0.0608	0.2673	0.1056	-0.3339	0.2259	-0.0675
Fare	0.2573	-0.5495	0.0911	0.1597	0.2162	1.0000	0.1823	-0.1823	0.2693	-0.1172	-0.1622	0.0109	0.1183	-0.1838	0.1052	0.0246
Sex_female	0.5434	-0.1319	-0.1174	0.1146	0.2455	0.1823	1.0000	-1.0000	0.0829	0.0741	-0.1192	-0.1599	0.6868	-0.8673	0.5476	-0.0345
Sex_male	-0.5434	0.1319	0.1174	-0.1146	-0.2455	-0.1823	-1.0000	1.0000	-0.0829	-0.0741	0.1192	0.1599	-0.6868	0.8673	-0.5476	0.0345
Embarked_C	0.1682	-0.2433	0.0414	-0.0595	-0.0111	0.2693	0.0829	-0.0829	1.0000	-0.1483	-0.7827	-0.0352	0.0262	-0.0726	0.0614	0.0654
Embarked_Q	0.0037	0.2210	-0.0478	-0.0264	-0.0812	-0.1172	0.0741	-0.0741	-0.1483	1.0000	-0.4994	0.0105	0.1711	-0.0783	-0.0897	-0.0078
Embarked_S	-0.1497	0.0741	-0.0062	0.0687	0.0608	-0.1622	-0.1192	0.1192	-0.7827	-0.4994	1.0000	0.0243	-0.1307	0.1129	0.0027	-0.0524
Title_Master	0.0852	0.0821	-0.4114	0.3496	0.2673	0.0109	-0.1599	0.1599	-0.0352	0.0105	0.0243	1.0000	-0.1098	-0.2549	-0.0876	-0.0383
Title_Miss	0.3271	-0.0006	-0.3047	0.0879	0.1056	0.1183	0.6868	-0.6868	0.0262	0.1711	-0.1307	-0.1098	1.0000	-0.5957	-0.2047	-0.0896
Title_Mr	-0.5492	0.1427	0.2315	-0.2505	-0.3339	-0.1838	-0.8673	0.8673	-0.0726	-0.0783	0.1129	-0.2549	-0.5957	1.0000	-0.4750	-0.2078
Title_Mrs	0.3390	-0.1492	0.1870	0.0634	0.2259	0.1052	0.5476	-0.5476	0.0614	-0.0897	0.0027	-0.0876	-0.2047	-0.4750	1.0000	-0.0714
Title_Rare	0.0220	-0.2063	0.1682	-0.0364	-0.0675	0.0246	-0.0345	0.0345	0.0654	-0.0078	-0.0524	-0.0383	-0.0896	-0.2078	-0.0714	1.0000

In [61]:

import matplotlib.pyplot as plt
import seaborn as sns

sns.heatmap(df_corr, cmap='coolwarm', vmin=-1, vmax=1)

plt.show()

• 생각보다 'Age'가 매우 낮게 (0.1미만으로) 나와서 당황스러움. 노약자와 유소년층을 배려해서 구조하진 않았나보다... 그렇다면?

Age value에 따라 Category 분류: Weak column¶

In [62]:

df_age = df_train.copy()

df_age['Weak'] = 0

df_age['Weak'].value_counts()

Out[62]:

0    891
Name: Weak, dtype: int64

In [63]:

df_age.head()

Out[63]:

	Survived	Pclass	Age	SibSp	Parch	Fare	Sex_female	Sex_male	Embarked_C	Embarked_Q	Embarked_S	Title_Master	Title_Miss	Title_Mr	Title_Mrs	Title_Rare	Weak
PassengerId
1	0	3	22.0000	1	0	7.2500	0	1	0	0	1	0	0	1	0	0	0
2	1	1	38.0000	1	0	71.2833	1	0	1	0	0	0	0	0	1	0	0
3	1	3	26.0000	0	0	7.9250	1	0	0	0	1	0	1	0	0	0	0
4	1	1	35.0000	1	0	53.1000	1	0	0	0	1	0	0	0	1	0	0
5	0	3	35.0000	0	0	8.0500	0	1	0	0	1	0	0	1	0	0	0

In [64]:

df_age.loc[(df_age.Age <= 12) | (df_age.Age >= 65), 'Weak'] = 1

df_age.Weak.value_counts()

Out[64]:

0    807
1     84
Name: Weak, dtype: int64

In [65]:

df_corr = df_age.corr()

df_corr

Out[65]:

	Survived	Pclass	Age	SibSp	Parch	Fare	Sex_female	Sex_male	Embarked_C	Embarked_Q	Embarked_S	Title_Master	Title_Miss	Title_Mr	Title_Mrs	Title_Rare	Weak
Survived	1.0000	-0.3385	-0.0892	-0.0353	0.0816	0.2573	0.5434	-0.5434	0.1682	0.0037	-0.1497	0.0852	0.3271	-0.5492	0.3390	0.0220	0.0850
Pclass	-0.3385	1.0000	-0.3436	0.0831	0.0184	-0.5495	-0.1319	0.1319	-0.2433	0.2210	0.0741	0.0821	-0.0006	0.1427	-0.1492	-0.2063	0.0877
Age	-0.0892	-0.3436	1.0000	-0.2677	-0.1968	0.0911	-0.1174	0.1174	0.0414	-0.0478	-0.0062	-0.4114	-0.3047	0.2315	0.1870	0.1682	-0.4007
SibSp	-0.0353	0.0831	-0.2677	1.0000	0.4148	0.1597	0.1146	-0.1146	-0.0595	-0.0264	0.0687	0.3496	0.0879	-0.2505	0.0634	-0.0364	0.3452
Parch	0.0816	0.0184	-0.1968	0.4148	1.0000	0.2162	0.2455	-0.2455	-0.0111	-0.0812	0.0608	0.2673	0.1056	-0.3339	0.2259	-0.0675	0.3430
Fare	0.2573	-0.5495	0.0911	0.1597	0.2162	1.0000	0.1823	-0.1823	0.2693	-0.1172	-0.1622	0.0109	0.1183	-0.1838	0.1052	0.0246	-0.0066
Sex_female	0.5434	-0.1319	-0.1174	0.1146	0.2455	0.1823	1.0000	-1.0000	0.0829	0.0741	-0.1192	-0.1599	0.6868	-0.8673	0.5476	-0.0345	0.0193
Sex_male	-0.5434	0.1319	0.1174	-0.1146	-0.2455	-0.1823	-1.0000	1.0000	-0.0829	-0.0741	0.1192	0.1599	-0.6868	0.8673	-0.5476	0.0345	-0.0193
Embarked_C	0.1682	-0.2433	0.0414	-0.0595	-0.0111	0.2693	0.0829	-0.0829	1.0000	-0.1483	-0.7827	-0.0352	0.0262	-0.0726	0.0614	0.0654	0.0016
Embarked_Q	0.0037	0.2210	-0.0478	-0.0264	-0.0812	-0.1172	0.0741	-0.0741	-0.1483	1.0000	-0.4994	0.0105	0.1711	-0.0783	-0.0897	-0.0078	-0.0172
Embarked_S	-0.1497	0.0741	-0.0062	0.0687	0.0608	-0.1622	-0.1192	0.1192	-0.7827	-0.4994	1.0000	0.0243	-0.1307	0.1129	0.0027	-0.0524	0.0094
Title_Master	0.0852	0.0821	-0.4114	0.3496	0.2673	0.0109	-0.1599	0.1599	-0.0352	0.0105	0.0243	1.0000	-0.1098	-0.2549	-0.0876	-0.0383	0.6720
Title_Miss	0.3271	-0.0006	-0.3047	0.0879	0.1056	0.1183	0.6868	-0.6868	0.0262	0.1711	-0.1307	-0.1098	1.0000	-0.5957	-0.2047	-0.0896	0.1414
Title_Mr	-0.5492	0.1427	0.2315	-0.2505	-0.3339	-0.1838	-0.8673	0.8673	-0.0726	-0.0783	0.1129	-0.2549	-0.5957	1.0000	-0.4750	-0.2078	-0.2937
Title_Mrs	0.3390	-0.1492	0.1870	0.0634	0.2259	0.1052	0.5476	-0.5476	0.0614	-0.0897	0.0027	-0.0876	-0.2047	-0.4750	1.0000	-0.0714	-0.1303
Title_Rare	0.0220	-0.2063	0.1682	-0.0364	-0.0675	0.0246	-0.0345	0.0345	0.0654	-0.0078	-0.0524	-0.0383	-0.0896	-0.2078	-0.0714	1.0000	-0.0346
Weak	0.0850	0.0877	-0.4007	0.3452	0.3430	-0.0066	0.0193	-0.0193	0.0016	-0.0172	0.0094	0.6720	0.1414	-0.2937	-0.1303	-0.0346	1.0000

In [66]:

sns.heatmap(df_corr, cmap='coolwarm', vmax=1, vmin=-1)

plt.show()

• Age column value = $a$에 대해, $a \leq 12, 65 \leq a$일 때, Weak = 1로 설정했다. (노약자 표시)

• 그러나 상관계수는 여전히 약 0.084로 Survived와 Weak간의 관계는 거의 없음을 의미한다.

Kaggle Competition Submission¶

In [67]:

submission = pd.read_csv(f'https://raw.githubusercontent.com/dev-EthanJ/scikit-learn_Machine_Learning/main/data/titanic_test.csv', index_col=0)

submission.head()

Out[67]:

	Pclass	Name	Sex	Age	SibSp	Parch	Ticket	Fare	Cabin	Embarked
PassengerId
892	3	Kelly, Mr. James	male	34.5000	0	0	330911	7.8292	NaN	Q
893	3	Wilkes, Mrs. James (Ellen Needs)	female	47.0000	1	0	363272	7.0000	NaN	S
894	2	Myles, Mr. Thomas Francis	male	62.0000	0	0	240276	9.6875	NaN	Q
895	3	Wirz, Mr. Albert	male	27.0000	0	0	315154	8.6625	NaN	S
896	3	Hirvonen, Mrs. Alexander (Helga E Lindqvist)	female	22.0000	1	1	3101298	12.2875	NaN	S

In [67]:

In [68]:

def pre_processing(df_train: pd.DataFrame):
    df_train = df_train.drop(['Cabin'], axis=1)
    df_train.Embarked = df_train.Embarked.fillna('S')
    df_train = df_train.drop(columns=['Ticket'])
    df_train['Title'] = df_train.Name.str.extract('([A-Za-z]+)\.')
    title_unique = df_train.Title.unique()
    rare_list = [title for title in title_unique if df_train.Title.value_counts()[title] < 10]
    df_train.Title = df_train.Title.replace(rare_list, 'Rare')
    title_age_mean = df_train.groupby('Title')['Age'].mean()
    for title in df_train.Title.unique():
        df_train.loc[(df_train.Age.isnull()) & (df_train.Title == title), 'Age'] = title_age_mean[title]
    df_train = df_train.drop(columns=['Name'])
    df_train = pd.get_dummies(df_train, columns=['Sex', 'Embarked', 'Title'])

    return df_train

In [69]:

df_sub = pre_processing(submission)

df_sub.info()

<class 'pandas.core.frame.DataFrame'>
Int64Index: 418 entries, 892 to 1309
Data columns (total 15 columns):
 #   Column        Non-Null Count  Dtype
---  ------        --------------  -----
 0   Pclass        418 non-null    int64
 1   Age           418 non-null    float64
 2   SibSp         418 non-null    int64
 3   Parch         418 non-null    int64
 4   Fare          417 non-null    float64
 5   Sex_female    418 non-null    uint8
 6   Sex_male      418 non-null    uint8
 7   Embarked_C    418 non-null    uint8
 8   Embarked_Q    418 non-null    uint8
 9   Embarked_S    418 non-null    uint8
 10  Title_Master  418 non-null    uint8
 11  Title_Miss    418 non-null    uint8
 12  Title_Mr      418 non-null    uint8
 13  Title_Mrs     418 non-null    uint8
 14  Title_Rare    418 non-null    uint8
dtypes: float64(2), int64(3), uint8(10)
memory usage: 23.7 KB

In [70]:

df_sub.loc[df_sub.Fare.isnull(), 'Fare'] = df_sub.Fare.mean()

df_sub.head()

Out[70]:

	Pclass	Age	SibSp	Parch	Fare	Sex_female	Sex_male	Embarked_C	Embarked_Q	Embarked_S	Title_Master	Title_Miss	Title_Mr	Title_Mrs	Title_Rare
PassengerId
892	3	34.5000	0	0	7.8292	0	1	0	1	0	0	0	1	0	0
893	3	47.0000	1	0	7.0000	1	0	0	0	1	0	0	0	1	0
894	2	62.0000	0	0	9.6875	0	1	0	1	0	0	0	1	0	0
895	3	27.0000	0	0	8.6625	0	1	0	0	1	0	0	1	0	0
896	3	22.0000	1	1	12.2875	1	0	0	0	1	0	0	0	1	0

In [71]:

df_sub_scaled = mm_scaler.transform(df_sub)
pred = knn.predict(df_sub_scaled)

pred

Out[71]:

array([0, 1, 0, 1, 0, 0, 1, 0, 1, 0, 0, 0, 1, 0, 1, 1, 0, 0, 0, 0, 0, 1,
       1, 1, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 1, 0, 0, 0, 1,
       1, 0, 0, 0, 1, 0, 1, 0, 1, 1, 0, 0, 0, 0, 0, 1, 0, 0, 0, 1, 1, 1,
       1, 0, 0, 1, 1, 0, 1, 0, 1, 0, 0, 1, 0, 1, 1, 0, 1, 0, 0, 0, 1, 0,
       1, 1, 0, 0, 1, 0, 0, 0, 1, 0, 0, 0, 1, 0, 0, 0, 1, 0, 0, 0, 0, 0,
       0, 1, 1, 1, 1, 0, 0, 1, 0, 1, 1, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 1,
       0, 0, 0, 0, 0, 0, 1, 0, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 0, 0,
       0, 0, 1, 1, 0, 1, 1, 1, 1, 0, 0, 0, 0, 0, 1, 1, 0, 0, 0, 0, 0, 1,
       1, 0, 1, 1, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0,
       0, 1, 1, 1, 1, 1, 0, 0, 1, 0, 1, 0, 0, 0, 0, 1, 0, 0, 1, 0, 1, 0,
       1, 0, 1, 0, 1, 1, 0, 1, 0, 0, 0, 1, 0, 0, 0, 0, 0, 0, 1, 1, 1, 1,
       0, 0, 1, 0, 1, 0, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 1, 0, 0, 0, 1, 1,
       0, 0, 0, 0, 1, 0, 0, 0, 1, 1, 0, 1, 0, 0, 0, 0, 1, 1, 1, 1, 1, 0,
       0, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 1,
       0, 1, 0, 0, 0, 1, 1, 1, 0, 0, 1, 0, 0, 0, 0, 1, 1, 0, 1, 0, 0, 0,
       1, 0, 0, 1, 1, 1, 0, 0, 0, 1, 0, 0, 0, 1, 1, 0, 0, 1, 0, 1, 1, 0,
       0, 0, 1, 0, 1, 0, 0, 1, 0, 1, 1, 1, 1, 0, 0, 0, 1, 0, 0, 1, 1, 0,
       1, 1, 0, 0, 0, 0, 0, 0, 1, 0, 0, 1, 0, 0, 0, 0, 0, 1, 1, 0, 0, 1,
       0, 1, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 1, 1, 1, 1, 1, 0, 1, 0, 0, 1])

In [72]:

result = pd.DataFrame({'PassengerId':df_sub.index,'Survived':pred})

result.head()

Out[72]:

	PassengerId	Survived
0	892	0
1	893	1
2	894	0
3	895	1
4	896	0

In [73]:

result.to_csv('titanic_kNN_submission.csv', index=False)
